Attributes
784mMaximum Lifting Height
Q55rope material
6x19s+Fc-25Rope Type
25MMwire rope diameter
Electric Motor DrivePower Source
Equipment components: Q355, Winch main shaft: forged from Q45 steelMaterial
Place of Origin:Henan, China
Controller Cord Length:Standard: 10-15 m, Extendable:Customizable
Strap length:Not Applicable
Winch Mounting Location:Headframe sheave height, The horizontal distance from the winch to the wel, Winch drum width, Find a safe balance between azimuth and elevation, The optimal balance point for completing the winc
Model Number:2JK-2*1.25 P
Brand Name:Wanfeng
Application:Metal mines, non-ferrous metal mines, non metallic mines, Energy Mines, Vertical shafts, Inclined shafts, Tunnel construction, Material hoisting, Personnel transport
Customized support:OEM, ODM
End Type:Normal Stop, Fixed-point stop, Smooth deceleration stop, Emergency Stop
Product Type:Mining Hoist Winch, Mining Lift Winch, Mining Electric Hoist, Mining Drum Winch, Mining Shaft Winch, Mine hoist elevator, Mine elevator hoist
Remote control type:Not Applicable
rope length:1-2000m
Standard:CE, KA, MA, ISO 9001 Certification, Chinese GB standards, European EN standards
Strap width:Not Applicable
Voltage:Rated Voltage 380V/50hz, customized according to local voltage
Warranty:12 months
Winch Bar Design:Main Shaft Assembly, Speed Reducer, YE3 Motor, Coupling, Electrical Control
Drum Diameter:200cm
Drum Width:125cm
Maximum lift capacity:6Ton
Maximum lifting speed:7m/s
Wire Rope Diameter:25mm
Lifting Height/Transport Length:1st layer 222m 2nd layer 487m 3rd layer 784m
