Attributes
Lithium BatterySupport Battery
JapanPlace of Origin
BT3554-50Model Number
HIOKIBrand Name
0-5 VCharge/Discharge Voltage
LaserFlashlight
Input Resistance:1 kΩ
Maximum Measuring Voltage:120 V
Type:Battery Capacity Tester
Resistance measurement range:3 mΩ
Voltage measurement range:± 6 V
Measurement range::-10°C to 60°C (14°F to 140°F)
Absolute max. input voltage:60 V DC max. (No AC input)
Measurement time:100 ms
Dimensions and mass:199 mm (7.83 in)W * 132 mm (5.20 in)H * 60.6 mm (2.39 in)D
Power supply:LR6 (size AA) alkaline battery *8
Temperature measurement:(-10.0 to 60.0 °C),
