Attributes
Roller-Bending Machinemachine type
4no. of roller
Aluminum, Carbon Steel, Brass / Copper, Alloy, Stainless Steelmaterial / metal processed
Automaticautomation
Motor, Pressure Vessel, Pumpcore components
2 Yearswarranty
max. working length (mm):2000 mm
max. plate thickness (mm):16 mm
place of origin:China
weight (kg):8000 KG
motor power (kw):11 kw
video outgoing-inspection:Provided
machinery test report:Provided
brand name:BEKE
extra services:End Forming
key selling points:Long Service Life
Model:W12-16x2000
Max. Thickness of plate:16mm(CS),12mm(CS)
Max. Pre-bending thickness:12mm(CS),10mm(SS)
Max. Width of plate:2000mm
The length of working rolls:2050mm
Up roller diameter:300mm
Bottom roller diameter:270mm
Side roller diameter:220mm
Minimum bending diameter:600mm
Yield limit:245MPa
