Attributi
PINNACLEMarca
AF020106Q1Numero del Modello
otherTipo di montaggio
Sichuan,ChinaPunto d'origine
Low noise amplifier chipDescrizione
Min/Typ/Max UnitParameter
Operating frequency:1/ /6 GHz
gain:/31/ dB
Gain flatness:/±0.8/ dB
Noise coefficient:/1.5/ dB
input return loss:/-15/ bit
Output Return Loss:/-15/ dB
P-1dB:/14.5/ dB
Quiescent current:/90/ dB
