Hoston High Precision CNC Slant Bed Gantry Type Lathe CK46 8-Piece Cutter Hot Selling in Turkey
No reviews yetComplies with EU standards
Complies with EU standards
Attributes
Customer's Requirementvoltage
SYNTECcnc control system
Light Dutymachining capacity
2number of axes
Singleno. of spindles
8tool post stations
max. length of workpiece (mm):220
key selling points:Competitive Price
repeatability (x/y/z) (mm):±0.002
positioning accuracy (mm):±0.002
warranty:1 Year
type:Horizontal
machinery test report:Provided
video outgoing-inspection:Provided
max. weight of workpiece(kg):100
travel (x axis)(mm):950
travel (z axis)(mm):290
place of origin:Jiangsu, China
width of bed (mm):45 mm
dimension(l*w*h):2160*1600*1800
brand name:Hoston
model number:CK46
weight:2600
range of spindle speed:0 - 5000
cutting torque:20
X/Y Positioning Accuracy:±0.002mm
X/Y Repeated Positioning Accuracy:±0.002mm
Slant bed degree:45°
Max cutting diameter:360mm
Chuck diameter:6 inch
Spindle nose:A2-5
Max bar diameter:45mm
Tool size:20*20mm
Color:Customer Optional
Function:Turning
Service
Free replacement parts & online technical support
1-year warranty
Key attributes
voltage
Customer's Requirement
cnc control system
SYNTEC
machining capacity
Light Duty
number of axes
2
no. of spindles
Single
tool post stations
8
max. length of workpiece (mm)
220
key selling points
Competitive Price
repeatability (x/y/z) (mm)
±0.002
positioning accuracy (mm)
±0.002
warranty
1 Year
type
Horizontal
machinery test report
Provided
video outgoing-inspection
Provided
max. weight of workpiece(kg)
100
travel (x axis)(mm)
950
travel (z axis)(mm)
290
place of origin
Jiangsu, China
width of bed (mm)
45 mm
dimension(l*w*h)
2160*1600*1800
brand name
Hoston
model number
CK46
weight
2600
range of spindle speed
0 - 5000
cutting torque
20
X/Y Positioning Accuracy
±0.002mm
X/Y Repeated Positioning Accuracy
±0.002mm
Slant bed degree
45°
Max cutting diameter
360mm
Chuck diameter
6 inch
Spindle nose
A2-5
Max bar diameter
45mm
Tool size
20*20mm
Color
Customer Optional
Function
Turning
Packaging and delivery
Selling Units
Single item
Single package size
216X160X180 cm
Single gross weight
2600.000 kg
Lead time
Product descriptions from the supplier
1 - 4 sets
$13,000
5 - 9 sets
$12,500
>= 10 sets
$12,000
Sample price: $13,000
