Input Voltage 9V-28V High Precision Measurement 50meter RS485 MODBUS Protocol Laser Distance Sensor
Store rating:4.7
(16 reviews)
Attributes
Laser Distance Sensortype
4.0 mradField of View
IP54, Ip68Ingress Protection
1.0 sLock-on Time
1XMagnification
Aluminum Alloymaterial
warranty:1 Year
place of origin:Shaanxi, China
size:90mm*61mm*30mm (length x Width x Height)
weight:150g
model number:FST-A1
Measurement Range:0.03---2M,5M,20M,50M
Ranging Blind zone:<30mm
Ambient light limitation:measured under strong sunlight, measuring range < 10 meters
Resolution:0.1mm
Repetition accuracy:±0.8mm(5m/10m/20m),±1.0mm(50m)
Response time:100ms
Laser Type Semiconductor:wavelength640nm red laser, Class 2 Eye safe
Measurement mode:Power on automatic measurement/command measurement
Power consumption ( the laser sensor):< 1W
Input voltage:9-32VDC
Service
Free replacement parts & online technical support
Key attributes
type
Laser Distance Sensor
Field of View
4.0 mrad
Ingress Protection
IP54, Ip68
Lock-on Time
1.0 s
Magnification
1X
material
Aluminum Alloy
warranty
1 Year
place of origin
Shaanxi, China
size
90mm*61mm*30mm (length x Width x Height)
weight
150g
model number
FST-A1
Measurement Range
0.03---2M,5M,20M,50M
Ranging Blind zone
<30mm
Ambient light limitation
measured under strong sunlight, measuring range < 10 meters
Resolution
0.1mm
Repetition accuracy
±0.8mm(5m/10m/20m),±1.0mm(50m)
Response time
100ms
Laser Type Semiconductor
wavelength640nm red laser, Class 2 Eye safe
Measurement mode
Power on automatic measurement/command measurement
Power consumption ( the laser sensor)
< 1W
Input voltage
9-32VDC
Packaging and delivery
Selling Units
Single item
Lead time
Minimum order quantity: 1 piece
$295
Variations
Select nowmeasurement accuracy: ±1 mm
±1 mm
Measurement Range
50 meters(164.04ft)
