Keithley DMM6500 High-Tech Graphic Touchscreen Digital Multimeter 6-Speed Electronic Measuring Instrument
Store rating:5.0
(5 reviews)1 sold
Attributes
1 yearswarranty
Shanghai, Chinaplace of origin
DMM6500model number
Keithleybrand name
metalmaterial
electricpower
Resolution:other
size:88 mm high X 213 mm wide X 410 mm
Parameters Measured:DC Current, AC Voltage, DC Voltage, AC Current
Input Bias Current:<50 pA at 23°C
Common Mode Current:<600 nA peak-peak at 50 Hz or 60 Hz
Overrange:20% on all ranges
Maximum 4-wire Lead Resistance:5 Ω per lead for 1 Ω range
Common Mode Rejection Ratio:>70 dB, for 1 kΩ unbalance in LO lead
Maximum Resolution:16 bits
Sampling Rate:Programmable 1 k through 1 MS/s
Key attributes
warranty
1 years
place of origin
Shanghai, China
model number
DMM6500
brand name
Keithley
material
metal
power
electric
Resolution
other
size
88 mm high X 213 mm wide X 410 mm
Parameters Measured
DC Current, AC Voltage, DC Voltage, AC Current
Input Bias Current
<50 pA at 23°C
Common Mode Current
<600 nA peak-peak at 50 Hz or 60 Hz
Overrange
20% on all ranges
Maximum 4-wire Lead Resistance
5 Ω per lead for 1 Ω range
Common Mode Rejection Ratio
>70 dB, for 1 kΩ unbalance in LO lead
Maximum Resolution
16 bits
Sampling Rate
Programmable 1 k through 1 MS/s
Packaging and delivery
Selling Units
Single item
Single package size
55X37X30 cm
Single gross weight
7.500 kg
Lead time
Product descriptions from the supplier
9 - 49 sets
$2,000
50 - 50 sets
$1,800
>= 51 sets
$1,500
Variations
Select nowcolor
Gray
Supplier’s customization ability
Minor customization
Drawing-based customization
Sample-based customization
Full customization
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
