YANGER Factory Direct CAT5E 4x2x24 AWG Solid SF/UTP LSZH-SHF1 Lan Cable Ethernet Network Communication Cables 0.25mm Insulation
Store rating:5.0
(1 review)+1 more
+1 more
Attributes
YANGERBrand Name
CAT 5e SF-UTPModel Number
Cat 5eType
Shanghai, ChinaPlace of Origin
8Number of Conductors
CopperConductor Material
Conductor Type:Solid
Install:0°C to + 60 °C, Bend minimum: 20 times O.D
Operate:-30°C to + 75 °C, Bend minimum: 10 times O.D.
Pull maximum:110 N
Weight:70 kg/km
Standards:ISO/IEC 11801/61156-1/61156-5 RoHS-2 2011/65/EU, UL1581
Insulation thickness:0.25 mm
Outer shield::Aluminum Foil-Polyester Tape
Drain wire::Solid Tin Copper
Outer jacket OD::6.8 ± 0.50 mm
Outer jacket color::Grey
Key attributes
Brand Name
YANGER
Model Number
CAT 5e SF-UTP
Type
Cat 5e
Place of Origin
Shanghai, China
Number of Conductors
8
Conductor Material
Copper
Conductor Type
Solid
Install
0°C to + 60 °C, Bend minimum: 20 times O.D
Operate
-30°C to + 75 °C, Bend minimum: 10 times O.D.
Pull maximum
110 N
Weight
70 kg/km
Standards
ISO/IEC 11801/61156-1/61156-5 RoHS-2 2011/65/EU, UL1581
Insulation thickness
0.25 mm
Outer shield:
Aluminum Foil-Polyester Tape
Drain wire:
Solid Tin Copper
Outer jacket OD:
6.8 ± 0.50 mm
Outer jacket color:
Grey
Packaging and delivery
Selling Units
Single item
Lead time
Product descriptions from the supplier
1000 - 4999 meters
$0.80
>= 5000 meters
$0.65
Variations
Select nowSpecification: CAT5E 4x2x24/1 AWG Solid SF/UTP LSZH-SHF1
CAT5E 4x2x24/1 AWG Solid SF/UTP LSZH-SHF1
Length
500M
Supplier’s customization ability
Minor customization
Drawing-based customization
Sample-based customization
Full customization
Shipping
Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.
